15kVA-60kVA

208/120VAC Three Phase

Mission Critical Availability while reducing costs with Scalable M90 Online UPS for 15kVA, 20kVA, 30kVA, 40kVA, 45kVA, 60kVA applications.

The M90U is a scalable modular online double conversion UPS that protects critical data and equipment from power problems while supplying clean and reliable network grade power.

M90U can be configured with a fully redundant power module and battery modules. Should one module fail, the remaining modules smoothly take over the load. The power modules are independent and can be hot swapped without risk to the critical load.

Product Snapshot

Six capacities: 15kW, 20kW, 30kW, 40kW, 45kW, 60kW
Modular for capacity or redundancy
Hot swappable power modules
Up to 98% ECO mode or 94% online efficiency
Remote control and monitoring options
2 year electronics, 2 year battery warranty (USA and Canada)

MODEL NUMBER M90U-15 M90U-20 M90U-30 M90U-40 M90U-45 M90U-60
INPUT Capacity 15kVA (13.5kW) 20kVA (18kW) 30kVA (27kW) 40kVA (36kW) 45kVA (40.5kW) 60kVA (54kW)

Nominal 208/120V 50/60Hz auto sensing

Range 121-253VAC*(L-L) 40-70Hz
OUTPUT Voltage 208/120VAC

Frequency 50/60 ± 0.05Hz

THD (full load) 0.9

Voltage regulation <2% Efficiency 98% ECO mode, ≥ 94% online mode Overload capacity 105%-110% for 60 min;110%-125% for 10min; 126%-150% for 1min; <150% for 200ms BATTERY SYSTEM Nominal voltage ±120V Temperature compensation Yes with optional sensor Charging current (programable) 8A 16A 24A 8A 16A 24A PHYSICAL Enclosure 20.3"W x 39.4"D x 54"H/484 lbs Power module 19.0”W x 28.0”D x 5.1”H / 74 lbs Battery module 4.1”W x 28.3”D x 6.0”H / 68 lbs ENVIRONMENT Temperature 0–40°C (32–104°F) Altitude 5,200 ft above sea level Audible noise < 65dBA at 1m APPROVALS UL-1778 (TUV), cUL, FCC A, RoHS WARRANTY 2 years (USA and Canada) COMMUNICATIONS INTERFACE RS-232, EPO, intelligent slot for optional cards (Web/SNMP, Relay, Modbus) INCLUDED IN BOX User manual, RS-232 cable, Ramp for unloading UPS enclosure AVAILABLE OPTIONS External maintenance bypass, 480V input transformer, output distribution, battery temperature sensor
