Product Specifications
Temperature Control Touch Screen control
Displays set point and chamber temperature
Hi/Low Alarm W/ Email and SMS notification
Alarm Relay Dry Contacts
Power Failure Dry Contacts
Battery Back-up
Viewable Temperature graph
Data logging downloadable via USB or FTP
Multi-Level Security
VNC Remote Access via PC / smart devices
Alarm System Battery operated alarm system will emit an audible and visual signal when there is a mechanical or electrical failure. The alarm has an over and under temperature setting, alarm silencing switch.
Remote Alarm Relay A relay for a remote alarm hook-up is also provided.
Access Port

Mounted in left hand side of the cabinet will be a 1/2″ porthole leading into the chilling chamber, complete with plugs.
Refrigeration System

One hermetic motor compressor. The compressor is the heavy duty industrial type: air cooled. The motor is sealed in oil for life and has thermoguard overload protection.
Construction Chamber is 14-ga. zinc coated galvanized steel. Exterior is 16-ga. steel. Powder coated cool gray finish.
Voltages Available 115/60/1 – 208/60/1 – 230/60/1 – 220/50/1
Technical Support Supplied by Nation-Wide-Network of service companies.
ETL Electrical Approval

Temperature Range: 0°C to -40°C

Capacity: 25 Cubic ft. / 710 Liters

Shelving: 4 Adjustable Shelves (5 Compartments)

Inventory Rack Capacity: 30

Dimensions:

Exterior w x d x h (inches): 50″ x 37″ x 79.5″

Exterior w x d x h (cm): 127 x 93 x 201

Interior w x d x h (inches): 34″ x 25″ x 51.25″

Interior w x d x h (cm): 86 x 63 x 130
