Thermo Scientific™ TSX Series high-performance -30°C auto defrost freezers are designed with features that support sample protection and sustainability objectives for the storage reagents, pharmaceuticals, vaccines, biological and other commonly used laboratory and clinical materials such as primers, siRNA molecules and fetal bovine serum (FBS) requiring -30°C. The Series’ V-drive technology is designed to provide temperature uniformity that continually adapts to user patterns, offering significant energy savings without compromising protection.

Certified to NSF/ANSI 456 Vaccine Storage* standard, the TSX series can help you meet regulations and guidelines from the CDC, World Health Organization, and other Health Ministries on vaccine storage and handling.

The TSX Series delivers the performance and quality you need, in addition to the low sound, low energy, and exceptional user experience you deserve.

*For NSF/ANSI 456 compliance, units must be ordered with a certificate of calibration (6916-2)

Product Line TSX Series
Certifications/Compliance UL, cUL, ENERGY STAR, NSF 456 (When Purchased with 6916-2 Calibration Certificate)
Capacity (English) 23 cu. ft.
Capacity (Metric) 650 L
Electrical Requirements 115V, 60Hz
Voltage 115 V
Frequency 60 Hz
Amperage 15 A
Plug Type NEMA 5-15
Dimensions (L x W x H) Exterior 37.8 x 28 x 78.6 in. (96 x 71.1 x 199.6 cm)
Dimensions (D x W x H) Interior 28.5 x 24 x 58 in. (72.3 x 61 x 147.3 cm)
Weight (English) 358 lb.
Weight (Metric) 162 kg
Shipping Weight (English) 423 lb.
Shipping Weight (Metric) 198 kg
Display Microprocessor
Refrigerant R290
Smart View Compatibility Smart-Vue Compatible
Chart Recorder Optional
Warranty Warranty varies by country, please contact us for details
Temperature (Setpoint) -35° to -15°C (-30°C)
Depth (English) Interior 28.5 in.
Depth (Metric) Interior 72.3 cm
Height (English) Exterior 78.6 in.
Height (English) Interior 58 in.
Height (Metric) Exterior 199.6 cm
Height (Metric) Interior 147.3 cm
Width (English) Interior 24 in.
Width (Metric) Interior 61 cm
Defrost Automatic
Width (English) Exterior 28 in.
Width (Metric) Exterior 71.1 cm
Depth (English) Exterior 37.8 in.
Type High-Performance Freezer
Depth (Metric) Exterior 96 cm
Green Features Energy efficient
Door Style Solid
Monitoring Options Wireless
No. of Doors 1
Rack Capacity 8
Shelves 4
Unit Size Each

The drive for sample integrity and security

Designed to safely store media, reagents, pharmaceuticals, vaccines, chemotherapy and other laboratory and medical-grade storage requiring a tight temperature performance
Unique V-drive technology is designed to detect usage patterns such as door openings when a higher compressor speed is needed and periods of stability where the compressor runs at a lower speed, saving energy without compromising protection
Non-invasive fully adaptive defrost with time and temperature guided cycle
Easy to use microprocessor control with interior light, setpoint security and alarms
Standard door locks provide comfort and assurance

Enabling compliance

Tested and Certified to NSF/ANSI 456 Vaccine Storage standard and supports the US CDC, WHO, and other global vaccine storage guidelines and recommendations*
Tested to GMP Clean Room Class A / ISO 5 & 6 (ISO EN 14644-1) with easy to clean surfaces support USP <797> and <800> hazardous drug compounding and other clean room environments
Tested and certified to conform with the design and safety standards of UL 471, 61010, and CE Directive 2011/65/EU and 2015/863

Designed for an ergonomic and comfortable experience

Ergonomically designed door handle with a soft-touch grip
The controller is angled to help prevent neck strain
Easy to clean and adjust epoxy coated shelves
Whisper quiet with a sound level of 52 dBA, enabling end users to work alongside the refrigerator without distraction
Self-closing door with 90° stop to assist with inventory loads

Verified sustainability

US EPA ENERGY STAR Certified with up to 50% less energy usage than conventional refrigerant models**
ACT Environmental Impact Factor Label Certified, providing third-party verification of the sustainable impacts of the product, its operations, and its end of life.
Natural, R290 refrigerants and water-blown foam make the TSX Series compliant with EU F-GAS regulations, U.S. Environmental Protection Agency’s Significant New Alternatives Policy (SNAP), and other Global Environmental Regulations.
Manufactured in an award-winning, zero-waste to landfill facility

Ready for connectivity and monitoring

Thermo Scientific™ DeviceLink™ Connect ready, enabling you to have a connected experience with your unit so you always—and anywhere— know the safety of your samples and the performance of your refrigerator or freezer.
Compatible with wireless monitoring systems and remote alarm contacts including our Thermo Scientific™ Smart-Vue™ Pro wireless monitoring systems

Make it your own

Alternate Door swing configuration and door types
Extra and Alternate wire baskets, shelves, and drawers
Free-standing or factory-installed chart recorders
Stainless Steel interior finish
E-Lock Adapter kits
4-20 milliamp transmitters and other remote alarm modules
Specialty, regional, and country specific plugs

Services and support

Industry Leading 120-month compressor warranty (varies by country, please contact us for details)
Optional Certificate of Calibration to an NIST (National Institute of Standards and Technology, formerly National Bureau of Standards) traceable instrument includes a model number and serial number certificate
Optional Validation Testing Programs include in house and field-based temperature mapping and Installation Qualification (IQ) and Operation Qualification (OQ) programs
Optional Factory Acceptance Test results including QC Test Log Sheets and QC Temperature Graphs

*For NSF/ANSI 456 compliance, units must be ordered with a certificate of calibration (6916-2)
** Data on file. Based on comparisons between TSX Series and previous generation Thermo Scientific models.
